Metra Electronics AXLOCM-80 Mini Line Output Converter; 2-Channel; 80 Watt; Metra Electronics AXLOCM-80

The LOC is designed to convert (2) channels of speaker level audio into (2) channels of line level audio that can be used by OEM amplifiers. It can also be used with OEM radios to add aftermarket amplifiers. This device will also detect the presence of an audio signal and then generate a +12V output that can be used to turn-on an aftermarket amplifier. Features and specifications The LOC is able to handle 40 watts per channel continuous input without overheating. The input circuitry is designed to correct the crossover distortion commonly found on standard LOCs, while providing a high to low level step down of 6:1. Output audio level is adjustable using the onboard, high quality potentiometers. The remote output or amplifier trigger is rated at 500mA (+12V) and will easily handle an outboard relay if additional current is needed. The remote output will trigger instantaneously when the LOC detects a DC voltage on the white, left + audio input wire above 5V or a very low audio signal. It will shut off 60 seconds after no signal is detected. Installation The LOC should be installed on a stereos speaker output wires, or the output wires on an OEM amplifier of up to 40 watts per channel. These wires can be found behind the stereo in the dash, on the output of an OEM amplifier, or on the input terminals on the OEM speakers. Please refer to the wiring diagram for the input connection details.

Specifications:

WARNING CA Proposition 65	Yes
WARNING CA Proposition 65 Message	WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Description_DES	Mini Line Output Converter
Description_EXT	Mini Line Output Converter; 2-Channel; 80 Watt;
Description_FAB	Worlds Smallest L.O.C.
Description_FAB	2-Channel Input
Description_FAB	Adjustable Gain For Each Channel
Description_FAB	150-Watt Max Per Channel
Description_FAB	12-Volt Signal Sense Turn-On
Description_MKT	The LOC is designed to convert (2) channels of speaker level audio into (2) channels of line level audio that can be used by OEM amplifiers. It can also be used with OEM radios to add aftermarket amplifiers. This device will also detect the presence of an audio signal and then generate a +12V output that can be used to turn-on an aftermarket amplifier. Features and specifications The LOC is able to handle 40 watts per channel continuous input without overheating. The input circuitry is designed to correct the crossover distortion commonly found on standard LOCs, while providing a high to low level step down of 6:1. Output audio level is adjustable using the onboard, high quality potentiometers. The remote output or amplifier trigger is rated at 500mA (+12V) and will easily handle an outboard relay if additional current is needed. The remote output will trigger instantaneously when the LOC detects a DC voltage on the white, left + audio input wire above 5V or a very low audio signal. It will shut off 60 seconds after no signal is detected. Installation The LOC should be installed on a stereo's speaker output wires, or the output wires on an OEM amplifier of up to 40 watts per channel. These wires can be found behind the stereo in the dash, on the output of an OEM amplifier, or on the input terminals on the OEM speakers. Please refer to the wiring diagram for the input connection details.
Description_MKT	The LOC is designed to convert (2) channels of speaker level audio into (2) channels of line level audio that can be used by OEM amplifiers. It can also be used with OEM radios to add aftermarket amplifiers. This device will also detect the presence of an audio signal and then generate a +12V output that can be used to turn-on an aftermarket amplifier. Features and specifications The LOC is able to handle 40 watts per channel continuous input without overheating. The input circuitry is designed to correct the crossover distortion commonly found on standard LOCs, while providing a high to low level step down of 6:1. Output audio level is adjustable using the onboard, high quality potentiometers. The remote output or amplifier trigger is rated at 500mA (+12V) and will easily handle an outboard relay if additional current is needed. The remote output will trigger instantaneously when the LOC detects a DC voltage on the white, left + audio input wire above 5V or a very low audio signal. It will shut off 60 seconds after no signal is detected. Installation The LOC should be installed on a stereos speaker output wires, or the output wires on an OEM amplifier of up to 40 watts per channel. These wires can be found behind the stereo in the dash, on the output of an OEM amplifier, or on the input terminals on the OEM speakers. Please refer to the wiring diagram for the input connection details.
Description_SHO	Line Level Converter
